Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: SBS, SBS
  • Model Number: Steel Structure Warehouse
  • Derusting: Ball Blast
  • Window: PVC or Aluminium Alloy Window
  • Materials: Q235b or Q345
  • Door: Sliding Door or Automatic Rolling Door
  • Color: By Customized
  • Connection: High Strength Bolt
  • Painting: Automatic Powder Coating or Painting
  • Size: By Customized
  • Design: By Customized

Packaging & Delivery

Packaging Details Seaworthy
Delivery Time within 30 ~45 days after receiving the deposit

Prefabricated Steel Structure Warehouse or Workshop Building

Product Description
  1. Steel structure components are made in the factory, which can reduce the workload, shorten the construction period, conform to the requirements of the industrialization, it can not only save resources but also reduce some unnecessary pollution
  2. The quality of steel structure factory production is reliable, precise size, easy to install, easy to cooperate with related department.3.
  3.  Light weight, high strength, the weight of steel structure building is 1/2 of the reinforced concrete building; Meet the needs of the houses are expounded and the net area is about 4% higher than that of reinforced concrete house.
  4. Steel can be recycled, thereless pollution to the environment construction and demolition. These advantages are the value of steel structure house. It used these advantages to prop up the "security umbrella" for life.
  5. Safety and reliability, good seismic and wind resistance performance, load capacity and seismic capacity can reach 8, flame to fail in the shock loss is its style.



Component

Specification

Main frame

Hot-dip galvanized or painted steel ,"H” steel, ”C” and ”Z ” cold-formed

thin-walled section steel

Roof

50mm-150mm EPS, PU, Rockwool sandwich panel/color steel roof sheet/

glazed roof tile

Wall

50mm-150mm EPS, PU, Rockwool sandwich panel.

Door

Sandwich panel door, security door or electric roller shutter door

Window

PVC sliding, aluminum alloy or shutter

Quotation

Below info needed for the quotation:

Project Name

steel structure

Size

total length and width, roof and eave height, roof pitch, etc

Roof and Wall

option: EPS, fiber glass, rock wool or PU sandwich panel

Door and Window

PVC or Aluminum alloy; sliding door or rolled door

Column and Beam

option:hot rooled or welded H section, I section; painting or galvanized

Purlin

option:C-Section or Z-section

Local Climate

1.wind speed  2.snow load 3.rain quantity 4.earthquake grade if have more details is preferred.

Crane Parameter

 If need crane beam, crane tons parameter and lift height are needed

Drawing

 1. according to clients' drawing

 2. design as per clients' dimension and requests

Package

Naked loaded in shipping container or as per requests.

Loading

 20 GP,  40HP, 40 GP,  40 OT





Technology 1

Gas shielded arc welding

Steel structures commonly use GMAW welding after assembly. Gas shielded arc welding regards the gas as a medium and takes the protection for the arc and welding area. Gas shielded arc welding enjoys good visibility to arc and weld pool. In addition, GMAW seldom has slag and obvious welding deformation.It is quite suitable for mechanized welding with spatial location.

Selection Guide for gas welding process parameters
A1 Wire diameter
Generally, the wire can be selected according to Table A1

Base metal thickness

≤4

>4

Wire diameter

0.5-1.2

1.0-1.6

Table A1


A2 Wire elongation
A2.1 The wire elongation relates to the wire diameter, the welding current and the welding voltage
A2.2 During the welding process, the distance from the tip to the base material is generally as 10-15 times as the wire diameter.
A3 Welding current
A3.1 Stick up the principle that base materials are in well welding penetration, welding current should be accurately selected in accordance with the thickness of base materials, joint type and the wire diameter.
 A3.2 The range of welding current in common use with variety of wire diameters shown in Table A2

Wire diameter

0.5

0.6

0.8

1.0

1.2

1.6

Welding currents

30-70

49-90

50-120

70-180

90-350

150-500

Table A2



Automatic Submerged Arc Welding
After H type steel structure being assembly, automatic submerged arc welding (gantry welding) is commonly taken into welding process. The automatic submerged arc welding is a kind of method named electric arc welding that the arc burning would be occurred in flux layers. Automatic submerged arc welding has outstanding advantages, there are high weld quality and brilliant protective effect of slag isolated from the air. Furthermore, the welding parameters can be automatically adjusted to maintain stability with stable welded composition and remarkable mechanical properties.

The selection of flux and wire
Mild steel in welding process can choose the flux with high manganese and silicon (HJ431) and work in with the wire in the type of H08MnA. While it could also use type flux with low manganese or no manganese (such as HJ130, HJ230, etc.) and match with the type of H08MnA or  H10Mn2 wire.
1,Welding with high strength and low alloy steel can choose the flux with fierce silicon (such as HJ350) or low manganese silicon (such as HJ250) and work in with the wire in appropriate high strength and low alloy steel (such as: H08MnMoA, H08Mn2MoA etc.)
2,Steel in heat resistant, low manganese and corrosion preventive can select flux with silicon or low silicon and with corresponding alloy steel wire during the welding process.
3,The high alloy steels such as the ferrite, the austenitic commonly choose the high alkalinity agglomerated flux or the solder bonding in order to reduce the burning loss and penetrated alloy  of alloy elements.

Production Process



Services

We can provide you with a complete service from quote, design, manufacture, etc, according to your requirements & drawing. The manufacture procedure including drilling, rust-removing, shot blasting, nondestructive detecting, painting and so on.

When designing and building any structure, there are many factors to consider such as safety, strength, cost and maintenance, etc. The materials must also be sustainable and environmental, thus to make a contribution towards the sustainability of the project itself.

Selecting the correct material for the task is vital, and this choice is now influenced by economic and environmental pressures that were not important several years ago. Save the tree and our earth, please choose light gauge steel framed house. Our technical and R&D support are ready to help you chose the correct grade of steel for each application, which can result in the most cost effective solutions for today's architecture, building and construction requirements.
