Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: SBS, SBS
  • Model Number: Steel Structure Warehouse
  • Name: Steel Structure Warehouse Building
  • Color: By Customized
  • Window: PVC or Aluminium Alloy Window
  • Materials: Q235b or Q345
  • Door: Sliding Door or Automatic Rolling Door
  • Connection: High Strength Bolt or Normal Bolt,etc.
  • Design: By Customized
  • Painting: Automatic Powder Coating or Painting
  • Size: By Customized

Packaging & Delivery

Packaging Details Seaworthy:
1.Container of 40'OPEN TOP,inside capacity is 12.01mx2.33mx2.15m,Gross weight of allocation is generally 27.0 tons,volumn is 60m3.
2.Container of 40 feet HIGH CUBE:Inside capacity is 11.8m x 2.34m x 2.18m,Gross weight of allocation is generally 22 ton,volumn is 54m3.
3.HC container of 45 feet:Inside capacity is 13.58m x 2.34m x 2.71m,Gross weight of allocation is generally 29 ton,volumn is 86m3
Hot Sale Customized Design Prefabricated Steel Structure Warehouse Building
Delivery Time within 30~45 days after receiving the deposit

Hot Sale Customized Design Prefabricated Steel Structure Warehouse Building

Product Description
  1. Steel structure components are made in the factory, which can reduce the workload, shorten the construction period, conform to the requirements of the industrialization, it can not only save resources but also reduce some unnecessary pollution
  2. The quality of steel structure factory production is reliable, precise size, easy to install, easy to cooperate with related department.3.
  3.  Light weight, high strength, the weight of steel structure building is 1/2 of the reinforced concrete building; Meet the needs of the houses are expounded and the net area is about 4% higher than that of reinforced concrete house.
  4. Steel can be recycled, thereless pollution to the environment construction and demolition. These advantages are the value of steel structure house. It used these advantages to prop up the "security umbrella" for life.
  5. Safety and reliability, good seismic and wind resistance performance, load capacity and seismic capacity can reach 8, flame to fail in the shock loss is its style.
Material List
ProjectSteel Structure Workshop
Building Size (m)78 x 30 (24) x 8.5 (7) m
itemSpecification
Main Steel Structure
steel pillarH(300-550)x200x6x10, steel Q345
steel beamH(300-550)x180x6x8, H300x180x6x8, steel Q345
Second Steel Structure
roof purlinC180*75*50*2.5
wall purlinC180*75*50*2.5
cross supportΦ20 round steel bar, steel Q235
column bracingΦ20 round steel bar, steel Q235
angle brace L50x4 angle steel, steel Q235
tie barΦ89*3, steel Q235
roof and wall panel
roof panel50mm sandwich panel
wall panel 50mm sandwich panel
rolling up doorauto-matic rolling up door
single wing doorsandwich panel door
edge covermade of steel sheet thickness 0.5mm
fittingsglass adhesive, self-tapping screw etc.
Other fittings
embeddedM24 steel Q235, process
intensive boltgrade 10.9
ordinary bolt4.8S



Production Process



Design Capability

Shengbang Steel Structure Co., Ltd. has professional designers who are able to R&D and various houses. Most of them have three years of working experience on steel structure design industry line. Our company adopts many advanced domestic and foreign design software to draw blueprint design, perspective view, construction drawing and detail drawing to meet requirements from different customers. At present, we have designed and produced plenty of foreign steel structure projects successfully and won high praise from overseas customers.

Design capabilities display as follow:



If you need our help you design, please provide the following information:

Usage

Steel Structure workshop,warehouse,office or so on.

Size

length*width*high, and the ridge height, slope

Standard

China Standard,England Standard,America Standard or Australia

Standard(please supply the detail date)

Crane

Do you need the crane?If you need please tell me the loding.

Country

Which country that the building will be?

Design load

Wind speed, Snow load, Earthquake

Wall and Roof

Steel sheet or sandwich panel

Insulation

Fiber glass, EPS,Rock wool,PU,please tell me the thickness

Surface

Painted (alkyd paint or Epoxy paint) ,Hot dip galvanize

Window

Quantity, material, dimension (W*H) and position

Door

Quantity, material, dimension (W*H) and position

Accessories

Down pipe, Out gutter, Ventilator, skylight etc.

Packaging & Shipping

Transportation is a one of the important process:

Steel structure is mainly composed of steel column, steel beam, steel frame and the rigid support and so on, so steel structure component volume is larger, The mainly transportation for export is as follow:

1. 40'HQ and 40'open top container

In general, after customer order, our engineering technology department design the steel structures will be according to the 40 'HQ and 40' open top container inside size      to design the shipment, in most cases, we use 40 'HQ and 40' open top shipping container shipment to pack steel structures.

2.Break bulk

At special circumstances, some large construction size will be more than 40 'HQ and 40' open top containers internal dimensions, we suggest customer use trucks, flatbed trailer etc to transport the large construction component to the pier from the factory, then ship by port lifting, so while booking space,customers should book the break bulk. We will cooperate with the customer to provide them the size and weight of the goods, in order to book a reasonable space.

Remark:

When components are shipped to the site, due to various reasons of transport may cause component deformation (generally for bending, damage to the paint film, etc.), can be in the scene to correct, at present the correction method is generally divided into cold straightening and hot straightening.

For bending component, do the mechanical gagging with oil pump, also can use flame (C2H2 and pure oxygen mixed) to the hot straightening, after correction, the paint film that damaged must be repaired.



Market



Services

We can provide you with a complete service from quote, design, manufacture, etc, according to your requirements & drawing. The manufacture procedure including drilling, rust-removing, shot blasting, nondestructive detecting, painting and so on.

When designing and building any structure, there are many factors to consider such as safety, strength, cost and maintenance, etc. The materials must also be sustainable and environmental, thus to make a contribution towards the sustainability of the project itself.

Selecting the correct material for the task is vital, and this choice is now influenced by economic and environmental pressures that were not important several years ago. Save the tree and our earth, please choose light gauge steel framed house. Our technical and R&D support are ready to help you chose the correct grade of steel for each application, which can result in the most cost effective solutions for today's architecture, building and construction requirements.

Ending words

Company Profile:


Foshan Shengbang Steel Structure Co., Ltd.Possesses professional large-scale steel structure production equipments and the automatic spraying production

line, so we can satisfy the different customers demand.We takes "build your future" as mission and takes company growth as premise.The company has trained many

high quality marketing personnel, professional technician and construction workers.We take the customers' demand as the guidances, then provide reasonable,

scientific and effective solution for customers.We regard practical growth, innovationand group solidarity as our company spirit, so that we can offer all round service to customers.

      FOSHAN SHENGBANG STEEL STRUCTURE CO., LTD



      Add:Pingtang Industrial Park, Shipeng Village, Shishan Town, Nanhai District,



            Foshan, Guangdong Province, China



      Tel:0086-757-63323396 Fax:0086-757-81196682
